  • ZGTT06 Self-propelled telescopic aerial workplatform
  • ZGTT06 Self-propelled telescopic aerial workplatform
ZGTT06 Self-propelled telescopic aerial workplatformZGTT06 Self-propelled telescopic aerial workplatform

ZGTT06 Self-propelled telescopic aerial workplatform

  • Product Item : ZG-TT06
  • Category: Aerial Platforms
  • Safe Working Load:159kg
  • Max Platform Height:6m
  • Lifting Motor/Drive Motor:1.3KW/0.5kw
  • INQUIRY   EMAIL


Product Description

ZG-TT06 is a self-propelled telescopic aerial work platform produced by SPZG, integrating flexible mobility and stable operation. Equipped with a retractable working platform, it can easily realize high-altitude lifting operations. It is suitable for both small and narrow spaces and conventional high-altitude operation scenarios, making it an ideal device to improve the efficiency and safety of high-altitude operations.

Product Features

  1. Flexible and Efficient: The minimum inner wheel turning radius is 0m, allowing flexible steering in narrow spaces; it supports self-propulsion in both retracted and lifted states for convenient movement.
  2. Safe and Reliable: Rated loads under different working conditions (159kg for the platform, 114kg for the extended platform) are set to ensure operational safety; the maximum working angle is only 5°, ensuring strong stability.
  3. Easy to Operate: The lifting speed is fast (52 seconds for lifting / 53 seconds for lowering), the battery has strong endurance (2×12V/100Ah), and it is equipped with a 24V/15A charger for convenient charging.
  4. Strong Adaptability: The compact overall size (1.35m in length, 0.80m in width) allows access to narrow areas; the climbing ability reaches 25%, which can handle slightly sloped sites.

Safe Working Load 159kg
Extended Platform Safe Working Load 114kg
Max Working Height 8m
Max Platform Height 6m
Overall Length 1.35m
Overall Width 0.80m
Overall Height 1.98m
Working Platform Size 1.28m×0.78m×1.1m
Platform Extension Size 0.51m
Min Ground Clearance (Retracted State) 0.08m
Min Ground Clearance (Lifted State) 0.023m
Overall Weight 1120kg
Wheelbase 1.04m
Min Turning Radius (Inner Wheel) 0m
Min Turning Radius (Outer Wheel) 1.4m
Lifting Motor/Drive Motor 1.3KW/0.5kw
Machine Travel Speed (Retracted State) 4km/h
Machine Travel Speed (Lifted State) 1.1km/h
Lifting/Lowering Speed 52/53 sec
Battery 2×12V/100Ah
Charger 24V/15A
Max Climbing Ability 25%
Max Allowable Working Angle
Tyre Φ305×100mm


Application Environment

  • Indoor Scenarios: Equipment maintenance in workshops, shelf organization in warehouses, ceiling maintenance in shopping malls/hotels, and other operations in narrow spaces.
  • Outdoor Scenarios: Building exterior wall cleaning, municipal facility maintenance, high-altitude garden pruning, and other operations on slightly sloped sites.
  • Other Scenarios: Temporary high-altitude installation, exhibition layout, and other high-altitude operation scenarios that require flexible movement.

Product Parameter Table



Product Services

  • After-sales Guarantee: Provide professional equipment installation guidance, operation training, and timely fault repair support.
  • Accessory Support: Supply original accessories for a long time to ensure the convenience and adaptability of subsequent equipment maintenance.
  • Consultation Channels: You can get product consultation, order docking and other services via WhatsApp/Skype/WeChat (+8613176910558) or email (myloader@vip.163.com).
